Structure
Medium duty trash compactor is composed of main machine body, compaction head, compaction cylinder, feed channel, lifting device, switching mechanism, steel platform, electronic control system, locking and positioning device, drain water discharging system, hydraulic system and control system and so on.
| Items | Technical parameter |
| Compaction cycle time /s | 50 |
| Working cycle time/min | 24 |
| Compaction cylinder volume/m3 | 5.4 |
| Dimension of compaction head /mm | Width 1900 |
| Height 700 | |
| Depth of compaction head/mm | Gate mechanism 450 |
| 450-1900 | |
| Max compaction force/KN | 420 |
| Container volume/m3 | 23 |
| Density after compaction/(kg/m3) | 750-800 |
| Rated working voltage/V | 380 |
| Total power/KW | 30 |
| Speed of travelling mechanism /(m/s) | 0.05-0.1(adjustable) |
Feature
1. The body of compaction device is made from high quality corrosion-resistant steel sheet with the thickness of 16mm. All the steel parts are treated with strict overall anticorrosion treatment and more than 120 hours salt spray test treatment.
2. The compaction head and container adopts small gap structure without lead rail, which is beneficial to reduce the wear between the compaction head and container and also good to more stable movement in the working process.
3. The medium duty trash compactor will not bring trash into the back of compaction cylinder and reduce cleaning workload.
4. We adopt automatic control and manual control, which is convenient for maintenance and debugging.
Huiqiang design and manufacture a wide range of municipal sanitation equipment, we are a reliable medium duty trash compactor manufacturer and supplier, offering waste collection and compaction equipment, garbage truck, road and street cleaning vehicle for environmental protection. With continuous research and development, Huiqiang offers quality trash compactor with competitive price.
