Functions
1. The compaction process can realize automatically cycle.
2. The solid waste compactor possesses fault diagnosis and displaying functions.
3. The compactor can automatically display the loading capacity of garbage and has overloading alarm annunciator.
4. Our solid waste compactor is equipped with emergency braking and force quit functions.
Model | |
Dimension(mm) | 6230×2500×2500 |
Effective volume of garbage container (m³) | 16 |
Loading capacity(T) | 13 |
Motor power(kw) | 5.5 |
Feature
1. We adopt new and advanced high power unit with less components, which is very convenient for maintenance and lower the cost of equipment maintenance.
2. The oil cylinder is equipped with durable seal ring and piston rod coated with special coating, which can improve the resistance against corrosive and acidic environment.
3. The drain outlet adopts standard 3-inch blow-off pipe and can effectively prevent pipe blocking.
4. The solid waste compactor is also equipped with external rear door locking mechanism to ensure the locking and sealing of garbage container.
5. The compactor is designed with trash sorting function and inserting corns and swiping cards function.
6. We adopt high pressure shot blasting derusting method and use wearproof and anticorrosion undercoat, finishing coat, highlight paint and apply stoving varnish process.
Huiqiang design and manufacture a wide range of municipal sanitation equipment, we are a reliable automatic solid waste compactor manufacturer and supplier, offering waste collection and compaction equipment, garbage truck, road and street cleaning vehicle for environmental protection. With continuous research and development, Huiqiang offers quality automatic solid waste compactor with competitive price.
