Description:
The BSQ series refuse compactor truck is high end compactor truck manufactured by VICON with independent research and development based on advanced Europe and USA technology. Different from domestic compactor truck, this series of refuse compactor truck have many advantages. For example, high end appearance, fashion look, superior performance, high capacity, etc. The compression ratio of this refuse compactor truck can reach 1:6, which is twice of common compactor truck. Besides, this refuse compactor truck is the only type that can collect large old furniture in China.
Currently, there are a series of refuse compactor truck, such as BSQ5070, BSQ5100, BSQ5160, BSQ5180, BSQ5250, etc. Bin lift device, rear bucket device and rear lid are optional for each type.
5250-20m³-12T
5160-12m³-8T
5100-8m³-5T
Technical parameter
Model
BSQ5070ZYSDFD5
BSQ5100ZYSDFD5
BSQ5160ZYSDFD5
BSQ5181ZYSDFD5
BSQ5250ZYSDFD5
Total Weight (kg)
7300
10000
15800
18000
25000
Volume of Container (m3)
6.8
8
12.5
16
20
Length (mm)
6860/6907
7264/7307
7798/7933
7598/8733
9490/9625
Width (mm)
2100
2310
2370
2370
2500
Height (mm)
2620
2710
3460
3460
3610
Wheel Base (mm)
3360
3800
3800
4500
4310+1350
Volume of the Hopper (m3)
2
2
3
3
3
Compaction Ratio
1:06
1:06
1:06
1:06
1:06
Recycling Time for Compression (s)
20
20
22
22
22
Time to Market
November
May
May
December
May
Features
Integrated design with smooth curve and fashionable appearance.
Integrated hopper with free feeding and no residue.
High compaction strength with compaction ratio of 1:6. The whole refuse compactor truck adopts high strength wear resistant steel design. With high bending strength and tensile strength, the refuse compactor truck can bear huge pressure. Besides, the whole refuse compactor truck has gone through finite element analysis, ensuring the reliability of the system. Mains parts of this refuse compactor truck has passed the nearly ten thousand times of effectiveness verification.
The cylinder adopts new types of installation for easy maintenance, reliability and durability, as well as ensuring the compaction strength effectively. The components of cylinder is located outside, the connection pieces adopts self-lubricating parts for avoiding maintenance.
Integrated design of hydraulic system and electronic parts to be convenient for maintenance.
Modular design for strong versatility, leading to cost reduction.
Main control components are exported abroad, the IP class of electronic components is IP67, resulting in higher reliability.
Equipped with automatic locking device for avoiding leakage, leading to higher reliability. Equipped with stay rod and hydraulic system balanced valve for higher safety.
Design of system optimization and productivity maximum. Equipped with flow control valve for adjusting the working speed with working load, leading to energy saving. Have the function of fault diagnosis, as well as be able to achieve bus control.
Design of large drain tank with volume of 1000L at maximum to satisfy different clients’ need.
The color of this refuse compactor truck is green. But we can design other color according to clients’ need.
